This is an outdoor rated, long-range PTP wireless data bridge for carrier-grade enterprise applications.  The radio operates at 5 GHz frequency, 802.11ac 2×2:2 (867 Mbps half-duplex rate). 700+ Mbps data throughput w/ W-Jet-V and ATPC. Dual gigabit Ethernet interfaces w/ IEEE 802.3af PoE passthrough. Integrated 23 dBi patch antenna for ease of installation. 2.4 GHz radio for management via mobile device. IP67. Metal enclosure. PoE injector and pole mount hardware included.

The Rapidfire antenna is a ultra high performance wireless bridge operating at 5 GHz.  This point-to-point system has exceptional performance that delivers 700+ Mbps throughput. The carrier grade design with a simple and friendly user interface makes RapidFire an ideal device for high capacity and performance demanding links.  Whether you are linking 2 building in the city, or have a short range connection through trees, this wireless bridge antenna will get the job done.

The Ligowave RapidFire antenna uses an integrated 23dBi panel antenna.  With the combined high transmit power of this radio, if you are installing the antennas close to one another (less than 500 feet), it is recommended to cross polarize the antennas, and turn the transmit power to the minimum of 6 dBm.  This will reduce transmit collisions, and keep the link operating at a more reliable throughput.

Powerful all in one hardware platform

New 1.2 GHz CPU dedicated for data processing delivers extremely high 250k PPS rate and swift performance of the PTP link. 2 x gigabit Ethernet ports with PoE pass-through allow building 1+1 (failover) or repeater links and also make PTP Rapidfire ideal for video surveillance scenarios. The ports are made according to 802.3at standard compliant.
An integrated surge and ESD protection is designed according to IEC standards and passes class 4 requirements.

Wireless configuration interface

Additional 2.4 GHz radio allows accessing your device wirelessly connecting with any type of device. This is extremely helpful when installing and setting up PTP links and then troubleshooting them in a difficult to reach conditions. Tests shown the radio is accessible even standing 20 meters away from a 10-story building when device is mounted on the top of the building.

Professional Design

Rock solid and easy to use mounting bracket ensures high wind-load survival and rapid deployment of the link. 45° integrated antenna tilt option increases flexibility when deploying links in a noisy areas. GORE-TEX gland allows pass-through of water vapor in humid conditions. Detachable handle makes it easy to carry the devices and works as additional tightening option of the device. Newly designed RGB LEDs indicate different devices statuses and signal level when aligning the antenna in 1 dBm step.

Outstanding capacity

Extremely high 750 Mbps capacity and carrier grade performance is ensured by a professional and powerful RF design supporting up to 256QAM modulation and 31 dBi (combined) radio output power with a total system gain of 172 dB. Proprietary protocol for data transmission (W-Jet V) specifically engineered for the PTP scenario delivers high performance even on a long distance links with high interferences and stabilizes the latency to 2-4 ms range.

Infinity Controller

The Infinity Controller is a wireless network management platform currently available for the NFT series and which will soon be coming to the LigoDLB and LigoPTP series. The controller allows users to install, manage, and expand NFT Wi-Fi networks using automated device onboarding, predefined network scenarios, and other features. The Infinity Controller for the DLB and PTP series will enable users to simplify the way they build, expand, and maintain their wireless networks.

Powerful OS

The LigoPTP operating system ensures easy and rapid deployment of point-to-point links with stable, fast performance. An intuitive and responsive user interface adjusts the layout based on the size of your screen. Essential tools including Setup Wizard, link test, antenna alignment, spectrum analyzer, and site survey are included to make set-up and troubleshooting more efficient. Automatic mechanisms such as auto-channel and automatic transmit power control optimize the link for maximum performance even in areas with high interference.

Available models

Radio

Wireless Protoco	W-Jet V
Radio Mode	MIMO 2×2
Frequency Range	4.900–6.100GHz
Channel Size	5,10, 20, 40,80 MHz
Modulation Schemes	OFDM (256-QAM, 64-QAM, 16-QAM, QPSK, BPSK)
Data Rates @ 80MHz	802.11 ac @ 40 MHz: 400, 360, 300, 270, 240, 180, 120, 90, 60, 30 Mbps 802.11 ac @ 80 MHz: 866, 780, 650, 585, 520, 390, 260, 195, 130, 65 Mbps
Duplexing Scheme	TTime division duplex
Error Correction	BCC, LDPC

Coming soon

Antenna

LigoPTP 5-23 RapidFire	LigoPTP 5-23 RapidFire
LigoPTP 5-N RapidFire	2 N-type connectors

Wired

First Interface	10/100/1000 Base-T with PoE IN (RJ45)
Second Interface	10/100/1000 Base-T with PoE OUT (RJ45)

Physical
Dimensions without mount

LigoPTP 5-23 RapidFire	Length 379 mm , width 387 mm , height 51 mm
LigoPTP 5-N RapidFire	Length 399 mm , width 174 mm, height 47 mm
Mount length till pole	124 mm

Weight including mount:

LigoPTP 6LigoPTP 5-23 RapidFire	3.9 kg (8.5 lb)
LigoPTP 5-N RapidFire	2.9 kg (6.3 lb)

Power

Power Input Method, Voltage	PoE 802.3at, Isolated 42–57VDC
Max Power Consumption	8.6W
Power Output Method, Voltage	PoE 802.3af, 48VDC, 12.95W Maximum
PoE inserter and AC/DC adapter is included in the box

Environmental

Operating Temperature	–40°C (–40°F) ~ +65°C (+149°F)
Humidity	0~90% (Non-Condensing)

Software features

• Wizard for fast link setup
• Centralized control from master: A) Common wireless link parameters; B) Individual slave parameters
• Smart Auto-channel
• Robust data security
• QoS with hardware acceleration
• Spectrum analyzer
• Wireless signal and device state indication on RGB LEDs
• Dual firmware image

Management

Dedicated 2.4GHz Radio for Management

System Monitoring	SNMP, GUI/HTTP(S), Shell/SSH and WNMS
System Configuration	GUI/HTTP(S) and WNMS

Regulatory

Certification

FCC/IC/CE

Antenna Specifications

Frequency Range	5.1 – 5.9 GHz
Gain	23dBi
Polarization	Dual linear
Cross-Pol Isolation	27dB
VSWR	<1.5
Azimuth Beamwidth (H-pol)	6°
Azimuth Beamwidth (V-pol)	7°
Elevation Beamwidth	9°
